XTCLH20M000TJEB7P0晶體振蕩器使用特點
來源：http://www.sdyoujian.cn 作者：億金電子 2019年03月25
村田是日本有名的電子元件制造商,所生產的陶瓷晶體諧振器,陶瓷晶振名列世界前排,高質量的產品獲得業界一致認可,是諸多客戶指定品牌.村田晶振集團擁有先進的生產技術,為了更好的服務廣大用戶,村田陶瓷晶振推出石英晶體諧振器,石英晶體振蕩器,包括TCXO和VC-TCXO振蕩器.
村田提供廣泛的TCXO晶振產品陣容（溫度補償晶體振蕩器）/VCTCXO（電壓控制溫度補償晶體振蕩器）,使用了高可靠性的晶體諧振器、卓越的溫度補償方法和調整方法,是村田經過多次試驗結合多年的經驗所研發制造.
| 村田晶振 | 頻率 | 頻率公差 | 工作溫度范圍 |
| XNCHH10M000TJEA2P0晶振 | 10.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCHH15M300TJEA0P0有源晶振 | 15.3000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| 村田XNCHH16M368TJEA4P0晶振 | 16.3680MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCHH16M800TJEA3P0貼片晶振 | 16.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCHH19M200TJEC1P0石英晶振 | 19.2000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCHH26M000TJEE5P0晶振 | 26.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCHH28M800TJEA1P0晶體振蕩器 | 28.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCHH32M000TJEB5P0 | 32.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCHH38M400TJEB3P0工業晶振 | 38.4000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCHH52M000TJEA1P0進口有源晶振 | 52.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCJH10M000TJEA8P0貼片晶振 | 10.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCJH15M300TJEA0P0石英晶振 | 15.3000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCJH16M800TJEA1P0石英晶體最大的器 | 16.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCJH19M200TJEA5P0石英晶振 | 19.2000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCJH26M000TJEB4P0晶振 | 26.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| 村田XNCJH28M800TJEA1P0晶振 | 28.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| 日本XNCJH38M400TJEA3P0進口晶振 | 38.4000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCJH52M000TJEA0P0有源晶振 | 52.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH10M000TJEA3P0有源晶體振蕩器 | 10.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH15M300TJEA2P0貼片晶振 | 15.3000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH16M800TJEA2P0石英晶振 | 16.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH19M200TJEB4P0晶振 | 19.2000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH20M950TJEA0P0晶體振蕩器 | 20.9500MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH21M250TJEA0P0石英晶振 | 21.2500MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH26M000TJEB1P0晶振 | 26.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH28M800TJEA0P0石英晶振 | 28.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH38M400TJEA1P0貼片晶振 | 38.4000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH52M000TJEA1P0石英晶體振蕩器 | 52.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCJH10M000TJEB0P0貼片晶振 | 10.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCJH15M300TJEA3P0有源晶振 | 15.3000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCJH16M800TJEB0P0晶振 | 16.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCJH19M200TJEB6P0貼片晶振 | 19.2000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCJH26M000TJEB4P0石英晶振 | 26.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCJH28M800TJEA0P0晶振 | 28.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCJH38M400TJEA3P0進口晶振 | 38.4000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCJH52M000TJEA5P0貼片晶振 | 52.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH10M000TJEB4P0石英晶振 | 10.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH13M000TJEA3P0有源晶振 | 13.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH16M800TJED2P0有源晶體振蕩器 | 16.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH19M200TJEC4P0貼片晶振 | 19.2000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH19M200TJJC3P0日本進口晶振 | 19.2000MHz | ±0.5ppmmax. (25±3℃) | -40℃ to 85℃ |
| XTCLH20M000TJEB7P0日產有源晶振 | 20.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH21M250TJEA0P0村田石英晶振 | 21.2500MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH25M000TJJA5P0村田晶振 | 25.0000MHz | ±0.5ppmmax. (25±3℃) | -40℃ to 85℃ |
| XTCLH26M000TJEA7P0村田貼片晶振 | 26.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH26M000TJJA6P0村田有源晶振 | 26.0000MHz | ±0.5ppmmax. (25±3℃) | -40℃ to 85℃ |
| XTCLH38M400TJEA0P0村田晶體振蕩器 | 38.4000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH40M000TJEB0P0晶振 | 40.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
村田晶體振蕩器使用特征
1.具有優良的高溫頻率穩定性
2.小尺寸,厚度薄
3.具有低電源電壓
4.SMD型（可回流焊接）自動貼片機上錫高效
5.村田有源晶振產品符合RoHS指令,不含鉛.
村田晶體振蕩器應用
1.商業無線電裝置
2.全球定位系統（全球導航衛星系統）
3.小型基站,移動通信設備
4.無線設備,無線藍牙
